Great smaller bike for a conversion that the team at My Ride Westgate converted
Bike specifications:
Bike Brand:
Trek
Bike Model:
Roscoe
Bike Year:
2020
Frame Size:
Small
Wheel Size:
27.5″
Bottom Bracket:
ISO threaded internal
Browse our popular conversion components:
Bafang BBS01 36V 300W Motor
Battery Extension Cable
Un-stocked Item
Bafang BBS02 36V 500W Motor
3 Pin Extension
Hourly service charge
Converted - Lighting Kit
Spacer Bling Ring 2mm 01/02
36V lithium ion battery DP-6-24ah
Lekkie Bling Ring HD
5 Pin Extension 30cm
Conversion specifications:
Motor:
Bafang BBS02 500watt
battery:
Other
Range:
40-60 Km
Extra parts needed:
Conversion report:
Motor Fitment 500w Bafang BBS02B with 5x 1mm BB spacer and 1x Lekkie Motorspacer 6mm + 4mm washers. Bafang 4-notch nut didn’t have lots of engagement but enough to lock it in. Needed Lekkie Axle extender for left crank frame clearance. Battery Wedge battery fit perfectly. Drivetrain Lekkie Bling Ring 40T 01/02 Package, 5mm of Bling Ring spacing and longer bolts.
Bike Performance:
the 500W bbs02 motor and smaller 24v battery you get a smooth, light riding experience with more than enough power to get you up steep hills, all while enjoying a smooth riding experience.
